Machine Description

CNC bending machines are the selling small sheet metal bending machine .Esay series press brakes adopts classic design.
The high-strength frame and simple torsion bar structure ensure the synchronization of both ends of the press brake and the smooth operation of the ram. It can bring stable bending performance.
High quality hydraulic system can burst out strong power and bending speed.
Which can edit bending depth and stopping dimension via digital control system. Simple operation, low maintenance cost, more economical
production & versatility Affordable price is a very good choice for simple bending workpieces. 30T ~ 400T optional.

NO.

Item

Parameters

Unit

1

Nominal pressure

2000

kn

2

Length of working table

3200

mm

3

Distance between uprights

2400

mm

4

Throat depth

400

mm

5

Ram stroke

250

mm

6

Adjusting volume of ram stroke

220

mm

7

Max open height

485

mm

8

Main power

15

kw

9

Length

3500

mm

10

Width

1800

mm

11

Height

2550

mm

12

Weight

10500

kg
