Heavy duty storage racks roll forming machine
Short Description:
Storage Rack/Beam/Upright Roll Forming Making Machinery
| No. | Main parameter of storage rack roll forming machine | |
| 1 | Suitable to process | Color steel plate |
| 2 | Width of the plate | As customer need |
| 3 | Thickness of the plate | 0.8-2.0mm |
| 4 | De-coiler | Manual one, can load 5 tons raw material |
| 5 | Rollers for forming | 20 rows |
| 6 | Diameter of the roller | Φ52mm |
| 7 | Rolling material | Carbon Steel 45# |
| 8 | Main motor power | 18.5kw |
| 9 | Productivity | 8-12m/min |
| 10 | Cutting method | Hydraulic mould cutting |
| 11 | Material of the cutting blade | Cr12 |
| 12 | Hydraulic cutting power | 5.5 kw |
| 13 | Processing precision | Within 1.00mm |
| 14 | Control system | Delta PLC control |
| 15 | Side panel of machine | 14mm |
| 16 | Main structure of the machine | 300 H steel |
| 17 | Weight | About 3.5T |
| 18 | Dimensions | 7.5*1.0*1.5m |
| 19 | Voltage | 380V 50Hz 3phases(changeable as n |
