galvanized steel round downpipe / downspouts machine
Short Description:
Basic Info
Delivery Time:30 Days
Warranty:12 Months
After Service:Engineers Available To Service Machinery Overseas
Type:Pipe Production Line
Cutting Mode:Flying Saw Cutting Or Mould Cutting
Material:GI, PPGI, Aluminum Coils
Material Of Cutting Blade:Cr12
Forming Speed:25-30m/min
Voltage:380V/3Phase/50Hz Or At Your Request
Way Of Driven:Chain Or Gear Box
Additional Info
Packaging:NUDE
Productivity:200 sets/year
Brand:YY
Transportation:Ocean
Place of Origin:Hebei
Supply Ability:200 sets/year
Certificate:CE/ISO9001
HS Code:84552210
Port:Tianjin Xingang
Product Description
galvanized steel round downpipe/ downspouts machine
100 galvanized steel round downpipe machine / downspouts machine could be used to make downspout pipes in a higher speed and good quality by 16 years in this area. For this machine, we take guide column frame style to make machine for making sure machine working speed and steady. And for the transmission, we will use gearbox with chain. The machine will be totally same as the following pictures shows.
Working Flow: Decoiler – Feeding guide – Main Roll Forming Machine – PLC Contol System – Hydraulic Cutting – Output Table
Technical parameters:
Raw material
PPGI or GI
Material thickness range
0.2-0.8mm
Rollers
18 rows
Material of forming rollers
45# steel with chromed
Shaft diameter and mateiral
76mm, material is 40Cr
Material of cutting blade
Cr12 mould steel with quenched treatment
Forming speed
12-15m/min(excluding cutting stoping time)
Main motor power
4 KW
Hydraulic station power
3KW
Mode of cutting
Hydraulic cutting or flying saw cutting or mould cutting
Control system
PLC Frequency Control System with touch screen
Pictures of machine:
Company information:
YINGYEE MACHINERY AND TECHNOLOGY SERVICE CO.,LTD
YINGYEE is the manufacturer specialized in various cold forming machineries and automatic production lines. We have a wonderful team with highly technology and excellent sales, which offer professional products and related service. We paid attention to quantity and after service, got great feedback and honor formal the clients. We have a great team for after service. We have sent several patch after service team to oversea to finish the products installation and adjustment. Our products were sold to more than 20 countries already. Also included US and Germany. Main product :
- Roof roll forming machine
- Roller Shutter Door Roll Forming Machine
- C and Z purlin roll forming machine
- Downpipe Roll Forming Machine
- Light Keel Roll Forming Machine
- Shearing Machine
- Hydraulic decoiler
- Bending machine
- Slitting machine
FAQ:
Training and Installation :
1. We offer installation service local in paid, reasonable charge.
2. QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.
Certification and after service:
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.
Our advantage:
1. Short delivery period
2. Effective communication
3. Interface customized.
Looking for ideal Rain Pipe Roll Forming Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Round Rainpipe Roll Forming Machine are quality guaranteed. We are China Origin Factory of Roll Forming Machine for Rainpipe. If you have any question, please feel free to contact us.
Product Categories : Downpipe Roll Forming Machine > Round Downpipe Roll Forming Machine
