Galvanized Steel Downpipe Roll Forming machine
Short Description:
Product Description:
The Steel downpipe roll former making machine are divided into two categories: Square Tube Seamless Steel Pipe Roll Forming Machine and Welded Steel Pipe Roll Forming Machine.
According to the cross-sectional shape can be divided into Square Tube Roll Forming Machine and Roll Forming Machine, which are widely used in circular steel pipe, but there are some semi-circular, hexagonal, equilateral triangle, octagonal shaped steel pipe.
Working Flow: Decoiler – Feeding guide – Main Roll Forming Machine – PLC Contol System – Hydraulic Cutting – Output Table
Technical parameters:
| Raw material | PPGI or GI |
| Material thickness range | 0.2-0.8mm |
| Rollers | 13-16 rows |
| Material of forming rollers | 45# steel with chromed |
| Shaft diameter and mateiral | 75mm, material is 40Cr |
| Material of cutting blade | Cr12 mould steel with quenched treatment |
| Forming speed | 10-15m/min(excluding cutting stoping time) |
| Main motor power | 5.5 KW |
| Hydraulic station power | 3KW |
| Mode of cutting | Hydraulic cutting or flying saw cutting or mould cutting |
| Control system | PLC Frequency Control System with touch screen |
